8 |
Introduction | AP70/AP80 Installation Manual
AP70, simple system example
T
T
T
12/24V DC
12 V DC
NSE
CAN BUS
DROP CABLES
NMEA 0183/
IEC 61162-1/
IEC 61162-2
TERMINATOR
RC42N
HS70
AP70 CONTROL UNIT
AC70
NMEA 0183 IN/OUT
DRIVE
UNIT
12/24V DC
QS80
TURN
MENUCMD
STBY AUTO NAV WORK
