Installation 1-50 CX34/44/54-series
Radar supply box RS4050 to run radar scanners RB714/5/6A
Addendum: 183-0700-003
Dimensions: H:125 mm, L:222 mm, D:81 mm
Power supply: 12 and 24 V DC (10-32 V DC max)
Fuses: Radar supply fuse 4A F
Main fuse 6A.3F
High voltage fuse 160 mAF
Radar motor fuse 6A.3F
Radar supply box RS4052 to run radar scanners RB717/8A
Addendum: 183-0700-004
Dimensions: H:161.9 mm, L:263 mm, D:91 mm
Power supply: 24 V DC (18-32 V DC max)
Fuses: Radar supply fuse 10 AT
Main fuse 6A.3F
High voltage fuse 200 mAF
Radar motor fuse 3.16AT
GPS section
Receiver type: 14 channel parallel, C/A code, 8 state Kalman filter
Accuracy: Position (DGPS): 2-5 m RMS
Position (SDGPS): 3-7 m RMS
Position (GPS): 8 m RMS
Speed: 0.1 kn
Course: 1°
Speed filter: 10 settings
Update rate: 1 second interval, typical
Dynamics: Velocity: 600 km/h
Acceleration: 10 m / s
2
GPS antenna GPS 5 DGPS antenna MGL-3
Type: Patch Patch and H-field
Dimensions:
H:100 mm (top=30, bottom=70)
H:75 mm
Diameter:86 mm Diameter:127 mm
Weight: 122 g (top=83, bottom=39) 600 g
Environment: -35°C to +75°C, 95% rel.
Mounting: 1” 14 thread (standard US)
Cable:
10 m RG58 (standard), 15 m RG223 (option), max. 30 m RG213
