Installation 1-52 CX34/44/54-series
Antenna: Slotted waveguide array, horizontal polarization, rotation rate
20-50 rpm.
- beam width: DX45 = 5.6° horizontal, 30° vertical.
DX60 = 3.8° horizontal, 30° vertical.
Housing: Casted aluminum and ASA.
Cables: 10m 153.3003.100
15m 153.3003.150
20m 153.3003.200
30m 153.3003.300
40m 153.3003.400
Radar radome scanners RB714A RB715A
Radome: 450 mm 650 mm
Scanner: 2 kW 4 kW
Range: to 24 nm to 36 nm
Rotation speed: 24 rpm 24 or 4 8rpm
Beamwidth: Horizontal 5.9° 3.9°
Vertical 25° 25°
Cables: 10m 153.3002.012 153.3002.015
15m 153.3002.013 153.3002.016
20m 153.3002.014 153.3002.017
30m 153.3002.314 153.3002.317
40m 153.3002.414 153.3002.417
Radar open scanners RB716A RB717A RB718A
Open array: 3 or 4 ft 4 or 6 ft 4 or 6 ft
Scanner: 4 kW 6 kW 12 kW
Range: to 48 nm to 72 nm to 96 nm
Rotation speed: 24 or 48 24 or 48 24 or 48
(24V) rpm (24V) rpm (24V) rpm
Beamwidth: Horizontal 2.5°, 1.8° 1.8°, 1.2° 1.8°, 1.2°
Vertical 22° 22° 22°
Cables: 10m 153.3002.008 153.3002.008 153.3002.008
15m 153.3002.009 153.3002.009 153.3002.009
20m 153.3002.010 153.3002.010 153.3002.010
30m 153.3002.030 153.3002.030 153.3002.310
40m 153.3002.040 153.3002.040 153.3002.410
