EQ33 Pilot menu Chapter 4-1
4. Pilot menu
2
PILOT
1
Highway
4.1 Highway display
To present any information in the EQ33 highway display will require
that a navigator is connected via the NMEA input port (PWR) - refer
to section 9.5 Electrical connections.
The connected navigator must be in navigation mode, which
could be Cursor, Waypoint, Route or Track navigation - see next
page.
4.2 Navigation setup
MENU
Call up the menu bar, and...
2,1
load Highway display
Since there is no navigation mode active, you will receive the legend:
NAVIGATION IS OFF. To enter the basic Navigation setup:
ENT
Load Navigation setup
Navigation setup:
XTE distance: 00.10nm
Alarm distance can be changed in this display, but alarm can only be
initiated from the connected navigator. Maximum setting in nautical
miles is 9.99 nm.
ENT
Return to Highway display
