DIP SWITCH SETTINGS
20221511 / D 93
Jumper settings on ICIF board
JUMPER DEFAULT FUNCTION DESCRIPTION
J5 Short Software installation Open = Software may be installed on ICIF
board
NOTE
: Make sure that also J1 on the IOPT
board is set to “Open”
NOTE
: Control unit will be damages if new
software is installed with this jumper
ON!
J6 Open CUP reset Used when resetting the CPU
J7 3-4 short Output port: ITERM board, TB1 “1TX”
1-2 short = IEC61162-2 or TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page
4)
NOTE
: Never use both jumpers at the same
time!
J8 3-4 short Output port: ITERM board, TB1 “2TX”
1-2 short = IEC61162-2 or TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page
4)
NOTE
: Never use both jumpers at the same
time!
J9 3-4 short Output port: ITERM board, TB1 “3TX”
1-2 short = IEC61162-2 or TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page
4)
NOTE
: Never use both jumpers at the same
time!
J10 3-4 short
Output serial signal
selection
Output port: ITERM board, TB1 “4TX”
1-2 short = IEC61162-2 or TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page
4)
NOTE
: Never use both jumpers at the same
time!
J11 1-2 short Polarity for “GPS”
signal setting
Input port: ITERM board, TB2 “GRX”
1-2 short = Standard
3-4 short = Reversed polarity
NOTE:
If a signal not is received with 1-2
short, 3-4 should be set to short.
NOTE
: Never use both jumpers at the same
time!
