Simrad GO7 Installation Manual

Specifications
Ú
Note: The most up-to-date specifications list is available at:
simrad-yachting.com
Mechanical/Environmental
Casing PC/ABS
Operating temp -15°C to +55°C (+5°F to +131°F)
Water ingress IPX6 and 7
Weight (excluding mounting
hardware)
1.310 kg
Screen brightness 1200nits
Screen resolution 480 x 800 (H x W)
Viewing angle in degrees
(typical value at contrast ratio =
10)
L/R: 70, top: 50, bottom: 60
Dimensions (overall) See dimensioned drawings
Electrical
Operating voltage 10 - 17 V DC
Current draw at 13.6V (sonar off,
max B/L)
1 A
Low power standby mode yes
Protection reverse polarity and temporary
over-voltage to 36V
Alarm output current 1 A max
Processor iMX61 single core
Conformity CE, C-Tick
Interfaces
NMEA 2000 (compliant) 1 port (Micro-C male)
Sonar 1 port (7 pin blue connector)
microSD card reader 1x microSD
8
Specifications | GO7 Installation Manual
53

Simrad GO7 Specifications

General

Resolution	800 x 480 pixels
Touchscreen	Yes
Networking	NMEA 2000
Bluetooth	Yes
Chartplotter	Yes
Display Size	7 inch
GPS Type	Internal
Wireless Connectivity	Wi-Fi
Chart Compatibility	C-MAP, Navionics
Display Type	TFT LCD
SD Card Slots	1
Sonar Compatibility	CHIRP
Radar Compatibility	Yes
Operating Temperature	-15°C to 55°C
Sonar	Broadband, CHIRP, DownScan, SideScan (with compatible transducer)
