Simrad R5000 Commissioning Manual

Software setup
Overview
Prior to use, the system requires a number of settings be configured in order for the system
to perform as expected.
Most settings are intended to be configured by the technician commissioning the system, by
the operator at first use, or by a technician after servicing or replacement of system parts.
Other settings are generic, and the system can be used with default values.
The installation settings are only available in service mode. Refer to "The settings dialog" on page
16 and "Access control" on page 16.
Ú
Note: Before starting the software setup, the system must be wired according to the
wiring instructions. All system units must be powered on. The O5000 Trackball must be
connected. All sensors must be available. At least one transceiver must be assigned to
one control station in the priority table. Refer to "Priorities table" on page 29
All the areas listed must be addressed during commissioning, and they should be stepped
through in the listed sequence.
When the setup is completed, the R5000 processor must be restarted. Refer to "Reboot device"
on page 19.
The settings are split between:
• control station settings: need to be done for each of the control stations in a multi-station
installation
• shared settings: can be done from any control station in the system
NMEA 0183 equivalence with IEC 61162-1/2
This device uses the term NMEA 0183 in menus and dialogs. NMEA 0183 is equivalent with
the IEC standard IEC 61162-1/2.
Control station settings
Control station settings are local settings for the control station. They need to be repeated for
each of the control stations in a multi-station installation.
1 O2000 configuration "Configuring the O2000" on page 17
2 Setting up the NMEA 0183 ports "NMEA 0183 setup" on page 31
3 Selecting sources "Sources" on page 28
4 LWE Own configuration "LWE Own configuration" on page 32
Shared settings
The settings listed are shared for the complete radar installation. These can be done from any
control station in the system.
1 Radar settings
• Radar sensor installation settings "Installation settings" on page 20
2 Own ship settings
• Own ship setup "Own ship setup" on page 35
• Own ship's AIS MMSI number "MMSI" on page 35
• Trial maneuver setup "Trial maneuver settings" on page 36
3 Control station settings
• Control station names "Control stations" on page 28
4
Software setup | R5000 Commissioning manual
15
