Fig . 31 . Later al and Longitudinal Feed Linkage
~io. 32. Timing Longitudinal Feed
STUD NUT
SPEED UP
a
Fig, 33, Timi ng Lateral Feed
20
TIMIHG THE FEED
HOTE : L ong i tud i nal f•cd timing shoul d be set be -
fo re m aki ng an y lateral timing a djustmen t.
Check:
Feed bar shown in Fig. 31 should be stopped
b eforo needle enters the button and shou ld no t begin
to move un til th& need le leaves the but ton.
LOHGITUDIHAL SETTI!o!G
Lo ngitud i na l feed mc. vement is timed by loos en-
ing the th r ee com mounting screws shown in f ig. 32
and rotating the com tow ar d le ft (as viewed from the
bottom of mac hine) to speed up t he l ongi tudin al fee d
io re la tion to needle move ment, or to ward right to
sl
ow down t he feed in relation to n ee d le m oveme nt.
When adjustme nt is correct ly se t, securel y ti ght-
en three com mounting scre ws .
LATERA L SETTIHG
Latera l feed moveme nt is tim ed by looseni ng the
st ud nut on l ateral r ock s ha ft roller show n in Fig .
33 and m ov ing roller to the l eft (as vi ewed fr om lop)
to s low down the latera l feed in rel ation to nee d le
m ove ment or toward right to spee d up the feed in
re l ation to need le movem en t .
When adjustment is correctly set, secure ly tig hten
stud n ut .
