PINCH SCREW
Fig. 39. Sett ing the Neodlo 8ar Height
NEEDLE BAR HEIGHT
CHECK:
Needle bor h eig ht shoul d be set so thot hook
point
i$ at top of needlo oyo at l oop tak ing (sec
Fig. 39).
SETTING:
With point of hook at centerline of needle, re-
move face plate and looson needle bar pinch screw
shown ir Fig. 39.
Raise or l ower need le bar as required to position
h ook point at top of needle eye . Securely tighten
needle bar pinch screw and replace face p late.
NOTE: A gouge for sotting needle bor height is
available upon specif1c r•quest at additional c,orge.
REEL WINDING ADJUSTMENTS
TRIPPING
POINT
~
~
,
Inset A
lnsat 8
PUSH ROD KHUR, et> LEVER ARM
"""\. ~)fT
CONNECTION LOCK
-
SCREW
-~
Fig. 40. Adjusting the Winding Linkage
23
WINDING LINKAGE
CHEO<
Reel winding linkogo •hould be ser ro clo"""' the
needre threod in throot of hook body as shown in
rnset A, Fig. 40.
SETTING:
Reml)ve cylinder arm cover and turn machine pul ley
unt1l tripping le ver rests on tripp1ng point as shown
in
1ruet B, Fig. 40. Thon loosen lever orm pinch
screw ond lock screw on knurled nut os shown. Make
certam that tripping lever remoms IN CON TACT
wt'h 1ripp109 pOint on feed com.
Boc< off on knurled nut one full turn from fully
engaged position ond compress push rod spring by
push1ng 1n on lover ornl until heavier bios of connec·
tion o;pring is felt. Hold this position wh ile tighten ing
lovar arm pinch screw.
Adjust lor POSITIVE CLAMPING ACTIOH o
reUricflng spring by turnmg knurled nut as required.
T.,en t1ghten lock screw on knurled nut and replace
cylinder arm cover.
