Singer 270 - Installation

BELT GUARD
COVER
TAB L E
YOKES
(/)
C'
Cl
e.
tNST ALLA TtON
Fig. 3. In stallation of Machine
~
Cl
"
j~
P loc:e machine into reces s on t ob le top on four
rubber cush i ons at corners of drip pan as shown.
Hinge pi ns fit int o hi nge pl ate s at back of recess
and should not support mochi ne except when it is
t ilte d back.
Install blower unit in acc o rda nce w ith instruc
4
tions on page 29.
Attach ad justa ble yokes to machine levers as
shown in Fig. 4.
Fig . 4. Attaching Yokes to Levers
Belt guard cover fits into bracke t and encloses
dr ive a nd stop mo tio n m ech a nis m (sec Fig. 3).
4
