Singer 270 - Page 84

Ref. Part
No. No.
1 548549
2 544502
3 548038
4 504056 (830)
5 548532
6 545363 (805)
7 548550
8 548477
9 545356 (803)
10
548476
11 545354 (B04)
12 548481
13 548478
14 548479
15 545355 (803)
16 548480
17 548531
18 548511
19 545370 (803)
20 548534
21 545138 (809)
22 548535
23 545365 (8 05)
24 548536
25 548537
26 · 545 364 (80S)
27 545441 (SUS)
28 •548093
29 •545340 (806)
STOP I.CVER, RAPID FEED TRIPPING PAWL
Description
Stop Lever Shaft
Stop Lever Crank with 504056 (830)
Stop
Lever Cr ank Position Pin
Stop
Lever Crank Set Screw
Stop
Lever Bracket
St op Lever B racket Scre w
Stop
Lever Spring
Rapid Feed Trip ping Pawl Lever
Rap id Feed Tripping Paw l Lever Hinge Screw
Rapid Feed Tripping P awl
Rapid Feed Trippin g Pawl Cap Screw
Rapid Feed Tripp ing Pawl Spring
Rap id Feed Tri pping Pawl Lever Br acket
Ra p id Feed T ripping I' awl Lever Brack et Position Pin (2)
Rapid Feed
Tripping Pawl Lever Bracket Screw
Rapid Fe ed Tripping Pawl Lever Bracket Screw Washer
Stop Le ver with 545370 (803)
Stop
Lever Position Pin
St op Lever Set Screw
Stop
Lever Friction Pad (rawhide)
Stop Lever Friction Pad Screw (2)
Stop Lever Interlocking Slide
Stop Lever Interlocking Slide Screw
Stop Lever Interlocking Slide Screw Washer
Stop
Lever Interlocking Slide Spring
Stop Lever Interlocking Slide Adjusting Screw
Stop
Lever Interlocking Slide Adjusting Screw N ut
Buttonhole Cutting Safety Latch Unlocking Plat e
Buttonhole
Cutting Safety Latch Unlocking Pl ate Screw (2)
-
