PERFORMANCE PARAMETERS
GTJZ0612E&0812E&1012E&1212E Operation Manual 1-7 © Mar. 2022
Table 1-4 GTJZ1212E Specifications (continued)
MEASURE
1212E (METRIC) 4047E (IMPERIAL)
Height (stowed, rails folded)
1.98m 6ft 6in
Height (stowed, rails up)
2.6m 8ft 6in
Wheel base 1.88m 6ft 2in
Wheel span
1.025m 3ft 4.4in
Ground clearance (pothole guards
retracted)
0.1m 4in
Ground clearance (pothole guards
deployed)
0.025m 0.98in
Tire size (diameter × width / type)
Φ380×125mm/solid Φ15×5in/solid
Platform dimension (Length × Width ×
Height)
2.3×1.15×1.1m 7ft 6.5in×3ft 9in×3ft 7in
PERFORMANCE PARAMETERS
Rated load capacity of platform 320kg
705.6 lb
Max. load capability of extended platform 120kg
265 lb
Max. platform occupancy (indoor/outdoor) 2 persons/1 person
Drive speed (stowed)
0~4 km/h
0～2.5 mph
Drive speed (raised)
0～0.8 km/h
0～0.5 mph
Uptime (in a no-load state)
63～68 s
Downtime (in a no-load state)
44～49 s
Gradeability
25%
Max. allowable inclination (front to back/left
to right)
3°/1.5°
Turning radius (inside)
0m 0ft
Turning radius (outside)
2.35m 7ft 8.5in.
Max. allowable manual force (indoor/
outdoor)
400N/200N 90 lbf/45 lbf
Max. noise 72dB
POWER PARAMETERS
Drive×Steer 2 WD×2 WS
Power unit motor (voltage/power) 24V DC, 3.3 kW
Hydraulic tank capacity
15L
3.3 gal (imperial)/4 gal (US)
Hydraulic system pressure
21MPa
3046 psi
Battery specification (voltage, capacity,
rate of discharge)-lead-acid battery
24 V, 280 Ah, 20 hr
Battery specification (voltage, capacity,
rate of discharge)-lithium battery
25.6 V, 200 Ah, 1 hr
