© Mar. 2022 1-8 GTJZ0612E&0812E&1012E&1212E Operation Manual
PERFORMANCE PARAMETERS
Table 1-4 GTJZ1212E Specifications (continued)
MEASURE
1212E (METRIC) 4047E (IMPERIAL)
Power system voltage
24VDC
System control voltage
24VDC
Charger (input voltage/output current)
100～240 V AC/30 A
Drive motor (voltage/power)
24 V /0.85 kW
GROUND BEARING DATA
Max wheel load
1180 kg
2601 lb
Pressure against ground
1255 kPa
182 psi
ENVIRONMENTAL REQUIREMENT
Max. allowable wind speed (indoor/
outdoor)
0 m/s/12.5 m/s
0 mph/28mph
Max. allowable altitude 1000m 3281ft
Allowable ambient temperature (lead-acid
batteries)
-10℃ to 40℃ 14℉ to 104℉
Allowable ambient temperature (lithium
batteries)
-20℃ to 40℃ -4℉ to 104℉
Max. allowable ambient relative humidity
90%
Storage condition
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environ-
ment with 90% relative humidity (20℃ [68℉]), and away from rain,
sun, corrosive gas and inflammables and explosives.
WEIGHT
Weight (in a no-load state) (indoor/
outdoor)
3210kg
7077 lb
Weight (in a no-load state) (indoor only) 3100kg
6834 lb
NOTE:
a) The platform height plus operator height (taken as 2m/6ft 7in) is the working height.
b) In different areas, hydraulic oil, engine oil, coolant, fuel and lubricant should be added in accordance with the en-
vironmental temperature.
c) In cold weather, auxiliary devices are needed to start the machines.
d) The ground bearing data is approximate values not considering different options and only applicable when it is
safe enough.
e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity.
f) The total vibration value of the platform does not exceed 2.5m/s², and the maximum root-mean-square value of
the weighted acceleration of the entire machine does not exceed 0.5m/s².
g) The hydraulic tank capacity is the maximum volume in the hydraulic tank.
