power and wait about two hours for the moisture to evaporate.
Parts Replacement: When the unit parts need to be replaced, user should make sure the service technician
use the replacement parts specified by the manufacturer or having the same characteristics as the original
part. Unauthorized replacement may put the unit In the risk of fire, electric shock or other hazards.
Safety Check: After all the maintenances and repairs are done, user is required to request the service
technician to conduct the overall safety check to ensure the machine is In the proper condition.
Feature SPEC
Accessories Main board (DB-M3602-02V01), ALi 48 Keys IR controller, USB HDD BOX(customer
option)
Board configuration 396MHz MIPS CPU, 128MB DDR400 RAM, Memory Clock 198Mhz, 2MB Serial
Flash, Single Tuner, DVB-S2 demodulator,
Power Supply Input 100V ~ 240V 50/60Hz
Power Consumption 30W Max / 1W Standby (it’s optional by customer’s board)
RS232 For FW Upgrading.
Standard Receiver Standard
DVB-S2 Standard (ETSI EN 302 307)
Input Frequency Range 950MHz ~ 2150Mhz
Input Signal Level -25dBm ~ -65dBm
Demodulation QPSK, 8PSK, 16APSK
Transport Stream MPEG-2 ISO/IEC 13818 Transport Stream Specification
MPEG Profile Level MPEG2 SD, MPEG2 HD, H.264/AVC SD, H.264/AVC HD
LNB Power & Polarisation Vertical +13.5V, Horizontal 18V, Current: MAX 500ma,
Multi Satellite receiving 22K switcher, DiSEqC1.0, DiSEqC1.1, Unicable , DiSEqC1.2, USAL
Conditional Access system 1 Common Interface Slots ; 1 CA card reader Slots
A/V Output ports YPrPb, RCA with CVBS, SCART with CVBS, HDMI(HDCP), Left/Right analog audio
output(RCA), Digital audio output(SPDIF with coaxial or fiber)
Aspect Ratio Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box.
Audio Decoding MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2, AC3.
Audio Mode Stereo/MONO/Left/Right
DVR supporting DVR with USB HDD, Time shifting with USB HDD
USB2.0 High Speed HOST 1 USB2.0 Port, USB media player to playback the media in USB flash disk or USB
HDD or USB card reader with memory card or FW Upgrading.
File system FAT12, FAT16, FAT32, NTFS (only support first partition)
Media Supporting JPG, BMP, MP3, WMA
Ethernet Interface 10/100Mbit
Storage Temperature
0℃ to +50℃
Operating temperature
CONTENTS
1. REMOTE CONTROLLER ...............................................................................................................................................7
