MODEL 3215 3219 3220 3226
Weight * 1090 kg 1170 kg 1542 kg 1896 kg
Width
Length
Platform Size
Working Height 6.4 m 7.6 m 8.1 m 9.9 m
Platform Elevated Height 4.6 m 5.8 m 6.1 m 7.9 m
Stowed Platform Height 0.88 m 0.99 m 0.97 m 1.1 m
Stowed Height Railings Up 1.88 m 1.99 m 2.1 m 2.3 m
Drive Height (All Standards)
Lift Time (No Load) 18 sec. 20 sec. 27 sec. 47 sec.
Lower Time (No Load) 32 sec. 39 sec. 41 sec. 63 sec.
Lift Time (Rated Load) 23 sec. 25 sec. 33 sec. 51 sec.
Lower Time (Rated Load) 24 sec. 29 sec. 29 sec. 46 sec.
Normal Drive Speed 3.0 km/h 3.8 km/h
Elevated Drive Speed 1.0 km/h 1.0 km/h
High Torque Drive Speed 1.5 km/h 1.9 km/h
Gradeability
Tires (Solid Rubber)
Type
Tank Capacity
60156AL-CE-1-R-S
Height
1.78 m
0.81 m 0.81 m
0.66 x 1.63 m
2.3 m
0.71 x 2.1 m
* Weight with standard 0.9 m extension platform.
(Refer to nameplate for aerial platforms with 1.5 m or 1.8 m extension platform.)
12 x 4 x 8 16 x 5 x 12
Hydraulic Oil
ATF Dexron III ATF Dexron III
10.9 L 30 L
23% 25%
N/A
1.05 km/h
3.2 km/h
FULL
Standard Operating Time
Chassis
