SKYJACK, Page 5SJIII Series
Section 2 - Maintenance Tables and Diagrams Service and Maintenance
Table 2.1b Specifications and Features (CE) (Continued)
MODEL 4620 4626 4632
Weight
†
1860 kg 2130 kg 2300 kg
Width
Length
Platform Size
Height
Working Height 7.92 m 9.75 m 11.6 m
Platform Elevated Height 6.1 m 7.9 m 9.7 m
Stowed Platform Height 0.97 m 1.14 m 1.23 m
Stowed Height Railings Up 1.96 m 2.15 m 2.24 m
Drive Height 6.1 m 7.9 m 9.7 m
Standard Operating Time
Lift Time (No Load) 24 sec. 48 sec. 50 sec.
Lower Time (No Load) 48 sec. 45 sec. 62 sec.
Lift Time (Rated Load) 32 sec. 54 sec. 59 sec.
Lower Time (Rated Load) 32 sec. 32 sec. 49 sec.
Chassis
Normal Drive Speed
Elevated Drive Speed
High Torque Drive Speed
Gradeability
Tires (Solid Rubber)
Type
Tank Capacity
60156AL-CE-2-R-S
3.2 km/h
16 x 5 x 12
0.90 km/h
25%
1.6 km/h
1
Fill hardness: 55 Durometer
†
Wei
g
ht with standard 0.9m extension
p
latform.
1.17 m
2.31 m
1.07 x 2.11 m
Refer to serial nameplate for specific applications.
ATF Dexron III
30 L
Hydraulic Oil
