SKYJACK, Page 8 SJIII Series
Section 2 - Maintenance Tables and DiagramsService and Maintenance
Floor Loading Pressure
Locally Concentrated Pressure (LCP): Overall Uniform Pressure (OUP):
Foot Print Area = Length x Width
Base Area = Length x Width
LCP = 0.4 X
Weight of Aerial Platform + Capacity
Foot Print Area
OUP =
Weight of Aerial Platform + Capacity
Base Area
WARNING
Intermixing tires of different types or using tires of types other than those originally supplied with
this equipment can adversely affect stability. Therefore, replace tires only with the exact original
Skyjack-approved type. Failure to operate with matched approved tires in good condition may
result in death or serious injury.
