SKYJACK, Page 11SJIII Series
Section 2 - Maintenance Tables and Diagrams Service and Maintenance
Table 2.2c Floor Loading Pressure (AS)
Wheel LCP** OUP**
kg kg
KPa (kN/m
2
) KPa (kN/m
2
)
min* 1089 435 689.5 7.5
max* 1361 544 758.5 9.5
min* 1170 468 689.5 8.0
max* 1420 568 758.5 10.0
min* 1542 633 758.5 8.5
max* 1950 878 896.5 11.5
min* 1860 746 827.5 10.0
max* 2091 836 896.5 11.5
min* 1860 744 1316.9 7.0
max* 2549 1021 1530.6 9.5
min* 2132 853 1420.3 8.0
max* 2685 1075 1544.4 10.1
min* 2302 921 1434.1 8.6
max* 2620 1048 1537.5 9.8
60354AF-AS-S
*
**
NOTE:
Total Aerial
Platform
Weight
Total Aerial Platform Load
MODEL
3219
4620
4626
4632
3220
3226
3215
OUP - Overall Uniform Pressure is a measure of the average load the aerial platform imparts on the
whole surface directly underneath it. The structure of the operating surface (beams, etc.) must be able
to withstand more than the indicated values above.
The LCP or OUP that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
min - Total aerial platform weight with no options
max - Aerial platform weight + all options + full capacity
LCP - Locally Concentrated Pressure is a measure of how hard the aerial platform presses on the
areas in direct contact with the floor. The floor covering (tile, carpet, etc.) must be able to withstand
more that the indicated values above.
