Wheel LCP** OUP**
kg kg
KPa (kN/m
2
) KPa (kN/m
2
)
min* 1089 435 689.5 7.5
max* 1361 544 758.5 9.5
min* 1170 468 689.5 8.0
max* 1420 568 758.5 10.0
min* 1542 616 758.5 8.5
max* 1950 780 896.5 11.5
min* 1896 746 827.5 10.0
max* 2091 836 896.5 11.5
min* 1922 744 1316.9 7.0
max* 2568 1021 1530.6 9.5
min* 2173 853 1420.3 8.0
max* 2627 1075 1544.4 10.1
min* 2303 921 1434.1 8.6
max* 2620 1048 1537.5 9.8
60354AH-CE-R
*
max - Aerial platform weight + all options + full capacity
**
NOTE:
The LCP or OUP that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
4626
4632
min - Total aerial platform weight with no options
LCP - Locally Concentrated Pressure is a measure of how hard the aerial platform presses on the
areas in direct contact with the floor. The floor covering (tile, carpet, etc.) must be able to withstand
more that the indicated values above.
OUP - Overall Uniform Pressure is a measure of the average load the aerial platform imparts on the
whole surface directly underneath it. The structure of the operating surface (beams, etc.) must be able
