No.
Skyjack
Part No.
Qty. Description
SKYJACK, Page 7SJIII Conventional Series
143911
Section 3 - System Component Identification and Schematics Service and Maintenance
3.5 Hydraulic Schematic Parts List
2H-13 103655 1 VALVE, Control (Lowering) (ANSI/CSA)
2H-13B 103655 1 VALVE, Control (Lowering) (CE)
2H-13-1 107269 1 VALVE, Control (Holding) (ANSI/CSA)
2H-13B-1 107269 1 VALVE, Control (Holding) (CE)
2H-13-2 107269 1 VALVE, Control (Holding) (ANSI/CSA)
2H-13B-2 107269 1 VALVE, Control (Holding) (CE)
2H-18A 104132 1 VALVE, Control (Differential)
2H-59B 132749 1 VALVE, Control (Proportional)
3H-14 106273 1 VALVE, Control (Lift)
3H-17A 103623 1 VALVE, Control (Brake)
3H-18A-1 103623 1 VALVE, Control (Speed A)
3H-18A-2 103623 1 VALVE, Control (Speed B)
4H-15 153334 1 VALVE, Control (Reverse drive) (Hytos) (includes 4H-16)
128317 1 VALVE, Control (Reverse drive) (Hytos) (includes 4H-16) (if equipped)
4H-16 - 1 VALVE, Control (Forward drive) (Hytos)
4H-23 153334 1 VALVE, Control (Right steer) (Hytos) (includes 4H-24)
128317 1 VALVE, Control (Right steer) (Hytos) (includes 4H-24) (if equipped)
4H-24 - 1 VALVE, Control (Left steer) (Hytos)
4H-26 113953 1 VALVE, Control (Powered plattform extend) (includes 4H-27)
(Models 3220/4620/4626)
4H-27 - 1 VALVE, Control (Powered platform retract) (Models 3220/4620/4626)
C1 124291 1 CYLINDER (Cushion)
C2 120989 1 CYLINDER (Lift) (Models 3220/4620)
120989 2 CYLINDER (Lift) (Models 3226/4626/4632)
C3 120236 1 CYLINDER (Steer)
C4 120220 2 CYLINDER (Brake) (Models 322x)
C5 127100 1 CYLINDER (Powered extension platform) (Models 3220/4620)
127100 2 CYLINDER (Powered extension platform) (Model 4626)
CB1 147889 1 VALVE, Counterbalance
CRV1 115299 1 VALVE, Cross-Over Relief (Option)
F1 109568 1 FILTER, Return
FD1 103354 1 VALVE, Flow divider/combiner
M1 103129 1 MOTOR, Hydraulic Wheel (Left hand) (Models 322x)
M2 103129 1 MOTOR, Hydraulic Wheel (Right hand) (Models 322x)
M3 134573 1 MOTOR, Hydraulic Wheel (Left hand) (Models 46xx)
M4 134573 1 MOTOR, Hydraulic Wheel (Right hand) (Models 46xx)
MB1 107354 1 BLOCK, Manifold (Main)
MB2 107493 1 BLOCK, Manifold (Emergency lowering)
MB3 111314 1 BLOCK, Manifold (Holding valve) (Models 3220/4620 ANSI/CSA)
111320 1 BLOCK, Manifold (Upper holding valve) (Models xx26/4632 ANSI/CSA)
111316 1 BLOCK, Manifold (Lower holding valve) (Models xx26/4632 ANSI/CSA)
130481 1 BLOCK, Manifold (Holding valve) (Models 3220/4620 CE)
130442 1 BLOCK, Manifold (Holding valve) (Models 3226/4626/4632 CE)
MB4 108195 1 BLOCK, Manifold (Rear drive)
MB5 -- 1 BLOCK, Manifold (Powered extension platform - part of cylinder weldment)
MB7 146563 1 BLOCK, Manifold (Brake release) (Models 46xx)
Parts list continued on the following page.
