No.
Skyjack
Part No.
Qty. Description
SKYJACK, Page 8 SJIII Conventional Series
143911
Service and Maintenance Section 3 - System Component Identification and Schematics
3.5 Hydraulic Schematic Parts List (Continued)
Parts list continued from the following page.
MB9 132748 1 BLOCK, Manifold (Proportional control)
O2 105530 1 ORIFICE (0.081” diameter) (Lowering) (Model 4632)
122213 1 ORIFICE (0.073” diameter) (Lowering) (Model 4620)
O3 105811 1 ORIFICE (0.040” diameter) (Steer)
O4 105281 1 ORIFICE (0.067” diameter) (Emergency lowering) (Models 3220/4620)
105281 2 ORIFICE (0.067” diameter) (Emergency lowering) (Models 3226/4626/4632)
O6 104434 1 ORIFICE (0.040” diameter) (Differential)
O7 104434 1 ORIFICE (0.040” diameter) (Brake) (Models 322x)
137127 1 ORIFICE (0.020” diameter) (Brake) (Models 46xx)
P1 106577 1 PUMP, Hydraulic (Model 4620, except EE rated)
106587 1 PUMP, Hydraulic (Models 4626/4632, except EE rated)
129961 1 PUMP, Hydraulic (ANSI/CSA EE rated)
129965 1 PUMP, Hydraulic (ANSI/CSA EE rated)
310567 1 PUMP, Hydraulic (Standard)
P2 146560 1 PUMP, Handle (Brake release) (Models 46xx)
PS1 102863 1 SWITCH, Pressure (Option)
113799 1 •BLOCK,Manifold
PT1 134431 - TRANSDUCER, Pressure (2000 psi) (Model 3220/4626/4632 CE)
134543 - TRANSDUCER, Pressure (1250 psi) (Model 3226 CE)
134432 - TRANSDUCER, Pressure (3000 psi) (Model 4620 CE)
R1 104534 1 VALVE, Relief (System)
R2 104534 1 VALVE, Relief (Lift)
R3 106557 2 VALVE, Relief (Holding valve) (Models 3226/4626/4632)
V1 107271 1 VALVE (Emergency lowering)
V2 103136 1 VALVE (Free-wheeling)
V3 146562 1 VALVE (Auto reset - brake release) (Models 46xx)
