Section 3 - System Component Identification and Schematics Service and Maintenance
3.6 Electrical Component Parts List
Parts list continued from the following page.
4H-23 153335 1 COIL, 24 Volt (Right steer spool valve) (Hytos)
128320 1 COIL, 24 Volt (Right steer spool valve) (Hytos) (if equipped)
4H-24 153335 1 COIL, 24 Volt (Left steer spool valve) (Hytos)
128320 1 COIL, 24 Volt (Left steer spool valve) (Hytos) (if equipped)
4H-26 103605 1 COIL, 24 Volt (Power extension platform extend) (option)
4H-27 103605 1 COIL, 24 Volt (Power extension platform retract) (option)
AT1 130440 1 TRANSDUCER, Angle
B1-B4 103480 4 BATTERY, 6 Volt (U2200)
B1-B4 106552 4 BATTERY, 6 Volt (U2500)
B1-B4 $ 4 BATTERY, 6 Volt (T2200)
BC 128537 1 CHARGER, Battery 24VDC (superior universal)
BCI 122093 1 BATTERY CHARGE INDICATOR
BP-29 103057 1 BEEPER, 24 VDC (ANSI/CSA)
BP-29 117967 1 BEEPER, 9-28 VDC (CE)
C1 146475 1 CONTACTOR, 24 Volt motor
CAP1 110699 1 CAPACITOR .47UF 50 Volts (ANSI/CSA)
CB1 117325 2 CIRCUIT BREAKER, 15 Amp
CB2 117325 2 CIRCUIT BREAKER, 15 Amp
CM1 130439 1 CONTROL MODULE, Integrated sensor (CE)
D02-X 129258 AR DIODE
D19A - ALARM OPTION
DA1 119758 1 DIODE PACK
DA2 119520 1 DIODE ASSEMBLY
DA3 119624 1 DIODE ASSEMBLY
DCM1 147664 1 MOTOR (24 VDC) (ANSI/CSA)
123477 1 MOTOR (24 VDC) (ANSI/CSA EE rated)
DXX 102921 AR DIODE
F1 310517 1 FUSE, 300 Amp (In-line fuse)
FL-22 121477 1 FLASHING LIGHT, 24VDC (option)
FL-29 103743 1 FLASHER (option) (ANSI/CSA)
H1 146649 1 HORN, Operator (Low tone)
LED-1 147061 1 POWER INDICATOR LIGHT (Platform control console)
LED-2 147061 1 POWER INDICATOR LIGHT (Base control console)
LS1A 121975 1 LIMIT SWITCH (High speed)
LS1B 121975 1 LIMIT SWITCH (High speed)
LS3 122014 1 LIMIT SWITCH (End of stroke - option) (ANSI/CSA)
LS4 125887 1 LIMIT SWITCH, Pothole protection (Battery tray) (ANSI/CSA & CE)
LS4 126051 1 LIMIT SWITCH, Pothole protection (Battery tray) (ANSI/CSA EE rated)
LS5 125885 1 LIMIT SWITCH, Pothole protection (Hydraulic tray) (ANSI/CSA & CE)
LS5 126060 1 LIMIT SWITCH, Pothole protection (Hydraulic tray) (ANSI/CSA EE rated)
LS6 121975 1 LIMIT SWITCH (Drive override)
PT1 134431 1 TRANSDUCER, Pressure 2000 psi (Models 3220/4626/4632 CE)
134432 1 TRANSDUCER, Pressure 3000 psi (Models 4620 CE)
134543 1 TRANSDUCER, Pressure 1250 psi (Models 3226 CE)
RST1 119629 1 RESISTOR, 2.7K ohms
RST2 146644 1 RESISTOR, 25W-30 Ohms
RST3 116505 1 RESISTOR, Low voltage protection
Parts list continued on the following page.
