Index
No.
Skyjack
Part No.
Qty. Description
SKYJACK, Page 12 SJIII Conventional Series
143911
Service and Maintenance Section 3 - System Component Identification and Schematics
3.6 Electrical Component Parts List (Continued)
Parts list continued from the following page.
S1 119725 1 SWITCH, Main power disconnect
S2 147054 2 N.O. CONTACT (Raise/Lower)
S3 147053 3 N.C. CONTACT (Lift/Drive)
147054 3 N.O. CONTACT (Lift/Drive) (without power extension platform)
4 N.O. CONTACT (Lift/Drive) (with power extension platform)
S4 147053 2 N.C. CONTACT (Emergency stop) (Platform control console)
S7 123994 1 CONTROLLER ASSEMBLY, Proportional
S7-1 122869 1 SWITCH, Neutral
S7-2 122877 1 SWITCH, Right steer
S7-3 122877 1 SWITCH, Left steer
S7-6 122872 1 SWITCH, Enable pushbutton
S8 147054 1 N.O. CONTACT (Horn)
S10 147053 2 N.C. CONTACT (Off/Platform)
147054 1 N.O. CONTACT (Base)
S11 102853 1 SWITCH (Powered extension platform extend/retract)
S12 102853 1 SWITCH (Powered extension platform enable)
S28 147053 1 N.C. CONTACT (Emergency stop) (Base control console)
TS1 146658 1 TILT SWITCH (Models 322x ANSI/CSA & EE rated)
146661 1 TILT SWITCH (Models 46xx ANSI/CSA & EE rated)
TT 103336 1 HOURMETER
