SECTION 6, Page 67
SJ-600 Series Engine Powered 112715
June 2001
Index
No.
Skyjack
Part No.
Description
Units
per
Assy.
A 900550 CENTER DRIVE Assembly -
1 121629 CAP, Output Shaft (2WD) 1
2 900329 • BOLT, M8X1.25X15 8
3 900328 • SEAL, Lip 3
4 900427 • FLANGE, Output Shaft 2
5 900490 • O-RING, Flange 3
6 900408 • HOUSING, Transfer Case, Front 1
7 900080 • PIN, Dowel 2
8 900321 • BEARING, 6210 4
9 900547 • GEAR, Input Shaft 1
10 121554 • Assembly, Output Shaft and Gear 1
11 900407 • HOUSING, Transfer Case, Rear 1
12 900071 • PLUG, Oil Drain 1
13 900283 • BOLT, M8X1.25X50 10
14 900072 • SEAL, Drain Plug 2
15 900650 • MAGNET, Ring 1
16 900643 • PLUG, Oil Drain 1
17 900370 • BREATHER 1
18 900553 • FITTING, 90° 1
19 900336 • FLANGE, Hydraulic motor 1
20 900414 • SHIM 1
21 900025 • BOLT, M8X1.25x22 8
22 114126 PLATE, Center Drive Motor Cover And Hose Bracket 1
23 109311 MOTOR, 2 Speed drive 1
103623 • VALVE, Series/parallel 1
355113 • MANIFOLD, Motor 1
103613 • COIL, Series/parallel valve 1
115340 • CHECK BALL 4
115338 • SEAL KIT 1
24 (Ref.) HARDWARE, Drive Motor Mounting -
103910 • BOLT, 1/2”-13 x 1.25” Grade 8 (Use Loctite 242 or equivalent) 2
103470 • WASHER, 1/2” Lock 2
25 105863 KIT, Universal joint AR
26 121585 SHAFT, Rear drive 1
27 103099 YOKE AR
900542 • BOOT, Output Shaft AR
Following items are used on 4WD machines
28 103099 YOKE AR
900542 • BOOT, Output Shaft AR
29 105863 KIT, Universal joint AR
30 111544 SHAFT, Front drive 1
31 103084 U-BOLT KIT 1
32 900655 KIT, SERVICE (9 Pieces)
(Consists of items 3(3), 5(3), 14(2) & 17(1))
FIGURE 6-23B. CENTER DRIVE AND DRIVE SHAFTS
(Haessler Drive Serial # 1690 and Below)
