SJ-600 Series Engine Powered 112715 SECTION 3, Page 7
June 2001
C1 121091 CYLINDER ASSEMBLY, Lift 1
Use Part # 110530 for Machines with Serial # 32328 and below.
C2 121091 CYLINDER ASSEMBLY, Lift 1
Use Part # 110530 for Machines with Serial # 32328 and below.
121095 • KIT, Seal repair AR
Use Part # 105888 for Machines with Serial # 32328 and below.
C5 112448 CYLINDER ASSEMBLY, Disc brake 1
112274 • KIT, Seal repair AR
C7 121086 CYLINDER ASSEMBLY, Steer (2WD/4WD) -
Use Part # 113356 for Machines with Serial # 32328 and below.
(Replaces 105325 for 2WD and 105335 for 4WD)
121108 • KIT, Seal repair (For cylinder, 121086) AR
113443 • KIT, Seal repair (For cylinder, 113356) AR
103762 • KIT, Seal repair (For cylinders, 105325 or 105335) AR
C8 107752 CYLINDER, Cushion 1
CV1 104624 CHECK VALVE, Small pump 1
CV2 104624 CHECK VALVE, Large pump 1
CV3 104624 CHECK VALVE, Lift 1
F1 109568 FILTER ASSEMBLY, Return 1
104254 • ELEMENT, Filter AR
HP2 110652 HAND PUMP, Brake release 1
M1 109311 MOTOR, Center drive hydraulic 1
M2 113875 MOTOR/PUMP with flow control 1
(hydraulic generator option)
MB1 114178 MANIFOLD BLOCK, Main 1
(Machines with serial number 30208 and above)
108009 MANIFOLD BLOCK, Main 1
(Machines with serial number 30207 and below)
MB2 103137 MANIFOLD BLOCK, Emergency lowering 1
MB3 106688 MANIFOLD BLOCK, Holding valve 1
MB4 106688 MANIFOLD BLOCK, Holding block 1
MB6 110666 MANIFOLD BLOCK, Lift 1
MB7 111943 MANIFOLD BLOCK, Auto reset brake 1
(Machines with serial number 30167 and above)
MB7A 110643 MANIFOLD BLOCK, Quick brake 1
(Machines with serial number 30166 and below)
MB9 103137 MANIFOLD BLOCK, Hydraulic generator valve (option) 1
MC1 110434 MOTION CONTROL ASSEMBLY 1
O1 104630 ORIFICE, Main lowering .096 diameter 1
O2 105501 ORIFICE, Lift cylinder .094 diameter 2
O3 113343 ORIFICE, Free-wheeling valve .104 diameter 1
O4 104435 ORIFICE, Manual lowering .067 diameter 1
OC1 114284 OIL COOLER ASSEMBLY (hyd. generator option) 1
P1 110460 PUMP, Dual inlet hydraulic .488/.854 1
(Machines with Kubota diesel engine)
114201 PUMP, Dual inlet hydraulic .366/.671 1
(Machines with Kubota gas engine)
NOTE: For service replacement of single inlet pump,
order dual inlet and conversion kit)
R1 104534 RELIEF VALVE, System 1
R2 104534 RELIEF VALVE, Lift 1
R3 106557 RELIEF VALVE, Lift cylinder 1
R4 106557 RELIEF VALVE, Lift cylinder 1
V1 107271 VALVE, Manual lowering 1
V6 113752 VALVE, Auto reset brake 1
(Machines with serial number 30167 and above)
2H-10A 104132 VALVE, Brake lock 1
(Machines with serial number 30166 and below)
2H-13B 103655 VALVE, Main lowering 1
2H-13B-1 107269 VALVE, Lift cylinder holding 1
2H-13B-2 107269 VALVE, Lift cylinder holding 1
2H-14B 103655 VALVE, Lift 1
2H-17A 114365 VALVE, Large pump dump 1
(Machines with serial number 30208 and above)
103656 VALVE, Large pump dump 1
(Machines with serial number 30207 and below)
2H-18A 103356 VALVE, Small pump dump 1
2H-25 102626 VALVE, Brake 1
(Machines with serial number 30167 and above)
110655 VALVE W/OVERRIDE, Quick brake 1
(Machines with serial number 30166 and below)
2H-30A-1 103656 VALVE, Brake dump 1
2H-30A-2 103656 VALVE, Brake feed 1
2H-30B 112218 VALVE, Free-wheeling 1
2H-86 104412 VALVE, Hydraulic generator (option) 1
3H-20A 103623 VALVE, Series/parallel 1
4H-15B 103396 VALVE, Reverse drive (includes 4H-16B)(Vickers) 1
128796 VALVE, Reverse drive (includes 4H-16B)(Hytos) 1
4H-16B 103396 VALVE, Forward drive (includes 4H-15B)(Vickers) 1
128796 VALVE, Forward drive (includes 4H-15B)(Hytos) 1
4H-23A 103397 VALVE, Right steer (includes 4H-24A)(Vickers) 1
128797 VALVE, Right steer (includes 4H-24A)(Hytos) 1
4H-24A 103397 VALVE, Left steer (includes 4H-23A)(Vickers) 1
128797 VALVE, Left steer (includes 4H-23A)(Hytos) 1
FIGURE 3.2-2. HYDRAULIC SCHEMATIC PARTS LIST FIGURE 3.2-2. HYDRAULIC SCHEMATIC PARTS LIST
Index
No.
Skyjack
Part No.
Description
Units
per
Assy.
Index
No.
Skyjack
Part No.
Description
Units
per
Assy.
