SECTION 6, Page 89
SJ-600 Series Engine Powered 112715
June 2001
A 114366 MANIFOLD ASSEMBLY, Main -
(Consists of items 1 thru 22)
1 114178 • Block, Main manifold 1
101446 BOLT, Stud 5/16” - 18 x 1 1/2” lg. 4
100397 NUT, Hex head 5/16” - 18 8
104637 WASHER, Lock 5/16” 4
103996 WASHER, Flat 5/16” S.A.E. 4
300117 WASHER, Fender 5/16 4
2 103397 • VALVE ASS’Y, “Vickers” steer (early models - replace with Hytos) 1
107440 • • COIL, 12 Volt Spool Valve 2
103920 • • BOLT, Socket head #10-24 x 2” grade 5 AR
128797 • VALVE ASS’Y, “Hytos” steer (later models & Vickers replacement) 1
128318 • • VALVE, Directional spool 1
128321 • • • COIL, 12 Volt Spool Valve 2
103920 • • BOLT, Socket head #10-24 x 2” grade 5 AR
3 103396 • VALVE ASS’Y, “Vickers” Drive (early models - replace with Hytos) 1
107441 • • COIL, 12 Volt Spool Valve 2
103943 • • BOLT, Socket head 1/4-20 x 2” grade 5 AR
128796 • VALVE ASS’Y, “Hytos” drive (later models & Vickers replacement) 1
128319 • • VALVE, Directional spool 1
128322 • • • COIL, 12 Volt Spool Valve 2
103942 • • BOLT, Socket head 1/4-20 x 1.75” grade 5 AR
4 103655 • VALVE, N.C. (brake feed) 1
5 103655 • VALVE, N.C. (lift) 1
6 103655 • VALVE, N.C. (lowering) 1
7 103656 • VALVE, N.O. (brake dump) 1
8 103656 • VALVE, N.O. (small pump dump) 1
9 114365 • VALVE, N.O. (large pump dump) 1
10 103613 • COIL, 12 Volt valve 5
11 106272 • COIL, 12 Volt valve 1
12 104534 • VALVE, Relief 2
13 104624 • VALVE, Pilot check 3
14 112187 • FITTING, Hose barb 1
15 103069 • FITTING, Connector #6orb-#6 3
16 102659 • FITTING, Connector #8orb-#8 6
17 104437 • FITTING, Plug hex-soc #6orb (port) 4
18 104630 • ORIFICE, Lowering .096 diameter 1
19 114518 • FITTING, Elbow 90° #6orb-#4 1
20 114520 • FITTING, Quick disconnect nipple 2
21 114521 • CAP, Quick disconnect dust 2
22 116128 • FITTING, Tee #8orb-#8-#4 (Later models) 1
114517 • FITTING, Tee #8orb-#6-#6 (Early models) 1
23 103329 • FITTING, Reducer #8-#6(Early models) 1
24 (Ref.) CONNECTORS, Valve electrical
104345 • • CONNECTOR, Gray AR
104409 • • CONNECTOR, Black AR
119825 • • CONNECTOR, Clear with Diode AR
Index
No.
Skyjack
Part No.
Description
Units
per
Assy.
FIGURE 6-36. MAIN MANIFOLD ASSEMBLY
(Machines With Serial # 30208 and Above)
