SECTION 6, Page 109
SJ-600 Series Engine Powered 112715
June 2001
Index
No.
Skyjack
Part No.
Description
Units
per
Assy.
FIGURE 6-47. ENGINE AND RELATED PARTS - Kubota Dual Fuel Engine
400062 ENGINE ASS’Y, Kubota dual fuel -
1 355061 • ENGINE, Kubota dual fuel (#DF-750E) 1
Use Engine #102840 for Machines with Serial # 31801 and Below.
• SOLENOID, Fuel shut-off #115305
• STARTER ASSEMBLY #115309
• ALTERNATOR ASSEMBLY #115329
• FLANGE, Air cleaner #115330
• ELEMENT, Air filter #115331
• FILTER, Oil #115337
• RADIATOR #115341
• DISTRIBUTOR #115342
• • GASKET, Distributor #115344
2 114527 • WELDMENT, Engine mounting LH 1
3 114455 • WELDMENT, Engine mounting RH 1
4 114422 • NEOPRENE, Anti-vibration 2
5 103904 • BOLT, Hex-hd 1/2-13 x 2” lg. 4
6 103468 • WASHER, Flat 1/2” 4
7 107949 • NUT, Hex Jam 1/2-13 4
8 115480 • BRACKET, Radiator support 1
9 116031 • SWIVEL, Ring 1
10 101860 • LINKAGE, Throttle 2
11 114684 • PIN, Roll 1/8” x 7/16” lg. 2
12 114709 • NUT, Hex 1/4-28 2
13 114707 • BOLT, Hex-hd 1/4-20 x 3-1/2” lg. 1
14 103980 • NUT, Hex 1/4-20 2
15 113582 • PLATE, Solenoid limit 1
16 400005 CLEANER ASSEMBLY, Air 1
115378 • CAP, Air cleaner 1
115379 • BAND, Air cleaner support 1
115386 • COVER, Air cleaner 1
113997 • INTAKE ASSEMBLY, Air 1
17 103962 • BOLT, Pan hd 10-32 x 1/2” lg. 4
18 104185 • WASHER, Lock #10 4
19 104694 • WASHER, Flat #10 2
20 103007 • SOLENOID 2
21 300039 • NUT, Hex nylock 1/4-20 1
22 104003 • NUT, Hex 10-32 2
23 114489 • BRACKET, Throttle solenoid 1
24 103078 • CLAMP, G10 4
25 103856 • BOLT, Hex-hd 1/4-20 x 3/4” lg. 2
26 104000 • WASHER, Lock 1/4 4
27 103995 • WASHER, Flat 1/4 4
28 115304 • PUMP, Fuel (included with Kubota Engine Item #1) 1
29 103321 • CLAMP, #4 Gear 6
30 355059 • BRACKET, Choke solenoid 1
31 114682 • CLAMP, #8 4
32 114708 • LANYARD 5”
33 300688 • SCREW, Slotted pan-hd. 8-32 x 1/4” lg. 1
34 103159 • FITTING, Elbow 90° (brass) 1
Parts list continued on the following page.
