SECTION 3, Page 11
SJ-600 Series Engine Powered 112715
June 2001
1 103334 CONTROLLER ASSEMBLY, Drive/steer (S7) 1
(For components, refer to Figure 6-9.)
2 103012 STRIP, Terminal block 1.5
3 114485 CABLE ASSEMBLY, Control box 16 pole 1
(Replaces cable with 28 pole round connector
by also ordering (1) CONNECTOR, 114477)
4 (Ref.) SWIT
CH ASSEMBLY, Lift enable (S9) 1
(For components, refer to Figure 6-8.)
5 (Ref.) SWITCH ASSEMBLY, Throttle select (S14) 1
(For components, refer to Figure 6-8.)
6 (Ref.) SWITCH ASSEMBLY, Range select (S29) 1
(For components, refer to Figure 6-8.)
7 (Ref.) SWITCH ASSEMBLY
, Up/down selector (S5) 1
(For components, refer to Figure 6-8.)
8 (Ref.) SWITCH ASSEMBLY, Emergency stop (S4) 1
(For components, refer to Figure 6-8.)
9 (Ref.) SWITCH ASSEMBLY
, Engine start push-button (S15) 1
(For components, refer to Figure 6-8.)
10 (Ref.) SWITCH ASSEMBLY
, Engine choke or glow plug 1
push-button (S13)
(For components, refer to Figure 6-8.)
11 (Ref.) SWITCH ASSEMBLY, Key select (S3) 1
(For components, refer to Figure 6-8.)
12 (Ref.) SWITCH ASSEMBLY, Power indicator (PL1) 1
(For components, refer to Figure 6-8.)
13 114373 SWITCH, Torque toggle (S41) (Later models) 1
FIGURE 3.3-1A. OPERATOR’S CONTROL BOX DIAGRAM - No Options
(Machines With Serial Number 32097 and Below)
Index
No.
Skyjack
Part No.
Description
Units
per
Assy.
