Skyjack SJ-7027 - Page 50

SECTION 3, Page 27
SJ-600 Series Engine Powered 112715
June 2001
Ref.
No.
Skyjack
Part No.
Description
Units
per
Assy
A (Ref). ANSI/SIA & CSA Models (Kubota Dual Fuel ) Serial #31801 and Below -
B (Ref.) ANSI/SIA & CSA Models (Kubota Dual Fuel ) Serial #31802 and Above -
C (Ref.) CE Models (Kubota Diesel) -
D (Ref.) All Models with Serial #33188 and Below -
E (Ref.) All Models with Serial #33189 and Above -
B1 103295 BA
TTERY, 12 Volt (starting) 1
BP-29 103056 BEEPER, 12 Volt 1
CAP1 103319 CAPACITOR, 35 Volt, 1000MFD 1
CB1 117326 CIRCUIT BREAKER, 20 Amp 1
CB2 117326 CIRCUIT BREAKER, 20 Amp 1
CB3 117326 CIRCUIT BREAKER, 20 Amp 1
CRD1 (Ref.) CABLE ASSEMBLY, Control box (See Section 6) 1
CRD2 (Ref.) CABLE ASSEMBLY, Scissor arm (See Section 6.) 1
CRD3 (Ref.) CABLE ASSEMBLY, Electrical panel (See Section 6) 1
CRD4 (Ref.) CABLE ASSEMBLY, Engine wiring (See Section 6) 1
CRD5 (Ref.) CABLE ASSEMBLY, Engine electrical (See Section 6) 1
CRD6 (Ref.) CABLE ASSEMBLY, Panel wiring (See Section 6) 1
CS-31A 103007 CHOKE SOLENOID, Engine 1
D10-D86 102921 DIODE AR
DCM1 300248 MOTOR, 12 Volt (powered ext. platform option) 1
F2 111282 FUSE, 100 Amp (powered ext. platform option) 1
F4 119469 FUSE, 200 Amp (Electrical inverter option) 1
FL-13B 103743 FLASHER 1
FL-22 121476 FLASHING LIGHT 1
H1 102850 HORN, 12 Volt 1
HTS-34A 103007 HIGH THROTTLE SOLENOID, Engine, A & B 1
HTS-34A 112721 HIGH THROTTLE SOLENOID, Engine, C 1
INV1 123629 INVERTER, 1500 Watt 120V @ 60hz 1
124047 INVERTER, 1500 Watt 110/220V @ 50hz 1
GPL1 KUBOTA GLOW PLUG INDICATOR LIGHT 1
GPT1 KUBOTA GLOW PLUG TIMER 1
LS4 111356 LIMIT SWITCH, End-of-stroke 1
LS5 102848 LIMIT SWITCH, High speed/tilt override 1
LS6-LS8 102848 LIMIT SWITCH, Scissor guards (Early models), C 3
OPS1 102838 SWITCH, Engine oil pressure 1
PL1 102671 CONTACT BLOCK, Power indicator light 1
S1 119726 SWITCH, Main power disconnect 1
S3 103141 N.O. CONTACT BLOCK, Off/lift/drive key switch 1
103225 N.C. CONTACT BLOCK, Off/lift/drive key switch 3
S4 103225 N.C. CONTACT BLOCK, Emergency stop switch 1
S5 103141 N.O. CONTACT BLOCK, Up/off/down switch 1
S7 103334 CONTROLLER ASSEMBLY, Drive/steer 1
Parts list continued on the following page.
FIGURE 3.4-1. ELECTRICAL PARTS LIST
