Page 68 December 2007
Rough Terrain Scissors
No. Label Pictorial Description
1
Electrical Panel (Model 6826)
Push “ ” to reset ground circuit breaker.
Push “ ” to reset power circuit breaker.
Push “ ” to stop engine and disable controls (Emergency Stop).
Light indicates controls enabled.
Push and hold “ ” to start engine.
Push and hold “ ” to operate choke (dual fuel) or “ ” glow
plugs (diesel).
Select “ ” gasoline or “ ” propane. Light “ ” indicates glow
plug operation (diesel).
Select “ ” to raise or “ ” to lower platform.
Select “ ” to enable platform controls, “ ” to allow engine to
run with no controls active or “ ” to enable base control console.
Read operating manual.
Engine Panel
1
Labels - Models 6826 & 6832
