SKYJACK, Page 27
April 2006
Start Operation Section 2 - Operation
SJ800 - E Series
Battery Powered
Warning
An operator should not use any aerial platform
that:
• does not appear to be working properly.
• has been damaged or appears to have worn
or missing parts.
• has alterations or modifications not approved
by the manufacturer.
• has safety devices which have been altered
or disabled.
• has been tagged or locked out for non-use
or repair.
Failure to avoid these hazards could result in
death or serious injury.
2.5-3 To Raise the Platform using the Base
Controls
Warning
Ensure that you maintain three points of contact
when using the ladder to mount/dismount
the platform.
1. Use the ladder of the aerial platform to access
the aerial platform deck.
2. Close the gate/chain.
3. On the operator’s control box, turn BASE/OFF/
PLATFORM select key switch to “BASE” position.
4. Ensure the emergency stop button is pulled out.
Warning
Ensure that you maintain three points of contact
when using the ladder to mount/dismount
the platform.
6. Use the ladder to dismount the platform.
2.5-5 To Raise the Platform using the Operator’s
Control Box
1. Ensure that the battery connector is properly
connected.
2. On the base controls, pull out the emergency stop
button.
Warning
Ensure that you maintain three points of contact
when using the ladder to mount/dismount
the platform.
4. Use the ladder of the aerial platform to access
the aerial platform deck.
5. Close the gate/chain.
Warning
Be aware of overhead obstructions or other possible
hazards around the machine when lifting.
7. Ensure that the battery connector is properly
connected.
8. Ensure the emergency stop button is pulled out.
9. Raise the platform by pressing “
××
××
×” (UP) with UP/
DOWN toggle switch. Release until the desired
height is reached.
2.5-4 To Lower the Platform using the Base
Controls
1. Lower the platform by pressing “Ø” (DOWN) with
UP/DOWN toggle switch. Release until the desired
height is reached.
Lowering Warning System - A lowering warning
system automatically stops the lowering function
before reaching the fully retracted position and
sounds the alarm. After the operator has released
the down controls and taken time to check that
no person is near the scissors, the lowering
function can be reactivated.
