April 2006
SKYJACK, Page 24
Section 2 - Operation Setup Procedure
SJ800 - E Series
Battery Powered
2.4 Setup Procedure
The following are descriptions of normal operating pro-
cedures. A qualified operator MUST read and com-
pletely understand these descriptions before operating
this aerial platform.
1. Before a new aerial platform is put into operation
it must be carefully inspected for any evidence of
damage resulting from shipment and inspected
periodically thereafter. Refer to Table 2-4,
Maintenance and Inspection Schedule.
2. Remove all packing materials and inspect for
damage incurred during transport. Report any
damage to delivery carrier immediately.
3. Inspect aerial platform thoroughly and remove any
foreign objects.
4. Raise all guardrails to their upright position and
lock in place with locking pins. Refer to
Section 2.2-11.
Warning
Before operating this aerial platform
check the guardrail system for loose or missing
locking pins. The guardrail system must be upright
and all pins must be locked in place.
Death or serious injury could result if the guardrail
system is not upright or properly locked.
5. Disconnect the battery connector.
6. Remove the operator’s control box from its
shipping container and secure it to the guardrail
at the right front of the platform.
7. Attach the control cable and power extension deck
cable (if equipped) to the machine’s control
cable.
8. Move the aerial platform to a firm, level test area
where the platform can be later vertically extended
to its maximum working height. If the aerial
platform is to be pushed, towed or winched, refer
to Section 2.7 for winching and towing procedure.
9. Unlock and open the hydraulic tank cabinet door.
10. Check the tank’s hydraulic oil level (scissor
assembly must be fully lowered). Level should be
at or slightly above the top mark on the sight glass.
Note
If required, add a quality grade hydraulic oil such as
ATF Dexron III (ESSO). Never mix hydraulic oils.
11. Close the hydraulic tank cabinet door.
12. Unlock and roll out the battery tray.
13. Check the battery fluid level. If fluid level is not at
FULL mark on the battery, add distilled or
demineralized water only.
Warning
Explosion Hazard
Keep flames and sparks away.
Do not smoke near batteries.
Warning
Battery Acid Is Extremely Corrosive
Wear proper eye and facial protection as well as
appropriate protective clothing.
If contact occurs, immediately flush with cold
water and seek medical attention.
14. Roll in the battery tray.
15. Connect the AC battery chargers cord to the
proper AC voltage source and charge the
batteries. Refer to Section 2.9 for battery charging
procedures. When charger cycle is complete,
disconnect battery charger AC cord.
