April 2006
SKYJACK, Page 40
Section 2 - Operation
Tables
SJ800 - E Series
Battery Powered
Table 2-1. Specifications and Features
Model 8831E 8841E
Weight* 4,898 kg 5,306 kg
Width 2.21m
Length 3.5 m
Platform Size 1.73 x 3.39 m
Elevated Working 11.28 m 14.3 m
Elevated Platform 9.4 m 12.5 m
Stowed Platform 1.50 m 1.75 m
Height
Drive 7.9 m
Standard 30 x 10-16.5 #6 Air filled 30 x 10-16.5 #6 Air filled
Tires
Optional #6 or #7 Foam filled
Normal Drive Max 4.2 km/h
Elevated Low Drive Max 0.8 km/h
Lift Rated Load 46 sec. 71 sec.
Speed
Lower Rated Load 48 sec. 60 sec.
Gradeability 30%
60125AE-CE
* Weights are approximate; refer to serial nameplate for specific weight. Values shown are for standard 2WD machines on air tires with
a manual extension platform Mid Size RT’s and no extension platforms Full Size RT’s.
