Section 3 – Familiarization Control functions
7
17
High-capacity zone indicator: This light shows
the MEWP is in the high platform capacity zone.
Refer to Section 7.7.
7
18
Platform rotation: This switch controls the left or
right rotation of the platform.
7
19
Generator (optional equipment): This switch
turns the generator on or off.
7
20
Boom/turret controller: This dual-axis lever
controls the raise or lower function of the main
boom, and the left or right rotation of the turret.
TM
1
3
4
+
STOP
=
2
+
1
2
3
4
5
6
7 8
91011131214151617181920
FAMILIARIZATION
To Next Page
