213205AAA SJ82 T, SJ86 T
76
Section 6 – Additional Procedures Move the MEWP for transport
6.6-3 Tie down the MEWP
1. Lock the turret with the turret transportation lock.
Refer to Section 6.6-1.
2. Turn the off/base/platform key switch to the
off position and remove the key before you
transport the MEWP..
3. Turn the main power disconnect switch to the off
position.
4. Use wheel chocks or blocks at the front and rear
side of the wheels if necessary.
5. Remove all loose or unsecured items.
WARNING
When you transport the MEWP, it must be attached
to a truck or trailer deck. Use the available
tie-down points to attach the MEWP. If you do not
obey, there is a risk of death or serious injury.
6. Tie-down the MEWP to the transport surface with
the tie-down points.
7. Put the lower platform mount between the boom
end and the platform to prevent side-to-side
movement of the boom. Do not use excessive
downward force when you secure the boom
section.
8. Put a block below the platform rotator. Carefully
lower the rotator onto the block and secure it in
position. Secure the strap below the hoses and
cables to prevent damage to the MEWP. Do not
use excessive downward force when you secure
the platform.
WARNING
Do an inspection of the MEWP for loose or
unsecured items.
NOTE
When you move the MEWP for transport with a
winch line, refer to Section 6.4.
optional equipment
Figure 06 SJ82 T Platform tie-down Figure 07 SJ86 T Platform tie-down
