Skyjack SJ82 T User Manual

213205AAA SJ82 T, SJ86 T
78
Section 7 – Technical Diagrams and Specications Technical diagrams
7.1 Technical diagrams
70
(21.34)
0 -5
(-1.52)
5
(1.52)
10
(3.05)
15
(4.57)
20
(6.10)
25
(7.62)
30
(9.14)
35
(10.67)
40
(12.19)
45
(13.72)
50
(15.24)
55
(16.76)
60
(18.29)
65
(19.81)
75
(22.86)
80
(24.38)
-10
(-3.05)
-15
(-4.57)
-5
(-1.52)
0
5
(1.52)
10
(3.05)
15
(4.57)
20
(6.10)
25
(7.62)
30
(9.14)
35
(10.67)
40
(12.19)
45
(13.72)
50
(15.24)
55
(16.76)
60
(18.29)
65
(19.81)
70
(21.34)
75
(22.86)
80
(24.38)
85
(25.91)
90
(27.43)
-10
(-3.05)
95
(28.95)
Feet (meters)
Figure 08 Reach diagram - SJ82 T
72.5 degrees
26 ft. 8 in. (8.13 m)
82 ft. (24.9 m)
88 ft. (26.8 m)
105 in.
2667 mm
72 ft. 6 in. (22.1 m)
12 degrees
7 ft. 3 in
16 in. (40.64 cm)
13.25 in. (33.65cm)
245 in. (622.3 cm)
53 in. (134.62 cm)
44 in. (111.76 cm)
19 in. (48.26 cm)
37 ft. 10 in. (11.53 m)
132 in. (335.3 cm)
24 in.
609.6mm
118 in. (3 m)
56 in.
[1422.4 mm]
98 in. (248.92 cm)
36 in. (91.4 cm)
96 in./72 in.
(243.8 cm/182.9 cm)
360 degrees
60 in. (152.4 cm)
63.7 in.
(2.21 m)
(161.8 cm)
283 in. (718.8 cm)
170 degrees
Figure 09 Dimensions - SJ82 T
