213205AAA SJ82 T, SJ86 T
86
Section 7 – Technical Diagrams and Specications Maximum platform capacities (evenly distributed)
7.7 Maximum platform capacities (evenly distributed)
7.8 Floor loading pressure
Model
Weights Pressures
Gross MEWP
Weight
Max Weight per
Wheel* LCP** OFL**
kg lb kg lb kPa psi kPa psf
SJ82 T - - 17 850 8100 175 1210 325 16.0
SJ86 T - - 17 850 8100 175 1210 330 16.0
1947AA
Gross MEWP weight: weight + platform capacity
* Wheel Load is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly
underneath the chassis. This has been calculated by dividing the MEWP weight by the overall oor area occupied by the MEWP
(on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must be able to withstand
more than the values indicated above.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
SJ82 T SJ86 T
Total Platform Capacity (High)
340 kg (750 lb)
3 Persons
Total Platform Capacity (Low)
227 kg (500 lb)
2 Persons
Wind Rating 12.5 m/s (28 mph)
Manual Side Force 400 N (90 lbf)
Tilt Cutout Setting (side-to-side x front-to-back) 5 degrees x 5 degrees
1945AA
