213205AAA SJ82 T, SJ86 T
70
Section 6 – Additional Procedures Chassis tilt recovery
6.2 Chassis tilt recovery
IMPORTANT
When you raise or extend the boom, the MEWP
must be on a rm, level surface.
WARNING
Tip-over hazard. If the tilt settings are exceeded,
the alarm makes a sound and the light illuminates.
The platform must be lowered and retracted
immediately. If you do not obey, there is a risk of
death or serious injury.
6.2-1 Platform uphill
If the MEWP becomes tilted with the platform uphill
(refer to Figure 02), follow the steps below to go back
to a lowered and retracted position.
1. Lower the jib to horizontal (if equipped)
2. Fully retract the main boom
3. Fully lower the boom.
4. Drive to a rm, level surface.
6.2-2 Platform downhill
If the MEWP becomes tilted with the platform downhill
(refer to Figure 03), follow the steps below to go back
to a lowered and retracted position.
1. Fully retract the boom.
2. Drive to a rm, level surface.
Figure 02 Platform uphill
Figure 03 Platform downhill
