5.4 Output Crosspoint
The output crosspoint allows any of the N dividers to connect to any of the R dividers and output drivers. Note that each output driver
has a specific R divider that is permanently attached and has the same subscript in the name, i.e., R3 and OUT3.
Table 5.10. Output Crosspoint Control Registers
Setting Name
Hex Address [Bit Field]
Function
Si5341 Si5340
OUT0_MUX_SEL
OUT1_MUX_SEL
OUT2_MUX_SEL
OUT3_MUX_SEL
OUT4_MUX_SEL
OUT5_MUX_SEL
OUT6_MUX_SEL
OUT7_MUX_SEL
OUT8_MUX_SEL
OUT9_MUX_SEL
010B[2:0]
0110[2:0]
0115[2:0]
011A[2:0]
011F[2:0]
0124[2:0]
0129[2:0]
012E[2:0]
0133[2:0]
013D[2:0]
0115[2:0]
011A[2:0]
0129[2:0]
012E[2:0]
—
—
—
—
—
—
Connects the output drivers to one of the N dividers. Selections
are N0, N1, N2, N3, and N4 for each output divider.
