2.1 Dividers
There are five divider classes within the Si5341/40. See Figure 2.2 Si5340 Detailed Block Diagram on page 11 for a block diagram
that shows all of these dividers.
• 1. Wide range input dividers Pfb, P2, P1, P0
• Only integer divider values
• Range is from 1 to 2
16
– 1
• Since the input to the phase detector needs to be
> 10 MHz, the practical range is limited to ~75 on the high side.
• Each divider has an update bit that must be written to cause a newly written divider value to take effect.
2. Narrow range input divider Pxaxb
• Only divides by 1, 2, 4, 8
3. Feedback M divider
• Ultra low jitter in fractional and integer modes
• MultiSynth divider
• Integer or fractional divide values
• 44 bit numerator, 32 bit denominator
• Practical range limited by phase detector range of 10–120 MHz and VCO range of 13500–14256 MHz
• This divider has an update bit that must be written to cause a newly written divider value to take effect.
4. Output N dividers
• Ultra low jitter in fractional and integer modes
• MultiSynth divider
• Integer or fractional divide values
• 44 bit numerator, 32 bit denominator
• Min value is 10
• Maximum value is 2
12
– 1
• Each N divider has an update bit that must be written to cause a newly written divider value to take effect. In addition there is
a global update bit that when written updates all N dividers.
5. Output R divider
• Only even integer divide values
• Min value is 2
• Maximum value is 2
25
– 2
Additionally, FSTEPW can be used to adjust the nominal output frequency in DCO mode. See Section 6. Digitally Controlled
Oscillator (DCO) Modes for more information and block diagrams on DCO mode.
