Register Address Description (Same as) Address
0x013D OUT9_MUX_SEL, OUT9_VDD_SEL_EN, OUT9_VDD_SEL, OUT9_INV 0x010B
Table 14.46. 0x013F-0x0140
Reg Address Bit Field Type Setting Name Description
0x013F 7:0 R/W OUTX_ALWAYS_ON This setting is managed by CBPro during zero delay
mode.
0x0140 11:8 R/W OUTX_ALWAYS_ON
Table 14.47. 0x0141
Reg Address Bit Field Type Setting Name Description
0x0141 5 R/W OUT_DIS_LOL_MS
K
Set by CBPro
0x0141 7 R/W OUT_DIS_MSK_LO
S_PFD
Set by CBPro
Table 14.48. 0x0145 Power Down All Outputs
Reg Address Bit Field Type Setting Name Description
0x0145 0 R/W OUT_PDN_ALL 0- no effect
1- all drivers powered down
