Table 14.53. 0x0212-0x0217 P1 Dividers
Reg Address Bit Field Type Setting Name Description
0x0212 7:0 R/W P1 48-bit Integer Number
0x0213 15:8 R/W P1
0x0214 23:16 R/W P1
0x0215 31:24 R/W P1
0x0216 39:32 R/W P1
0x0217 47:40 R/W P1
Table 14.54. 0x0218-0x021B P1 Divider Enable/Set
Reg Address Bit Field Type Setting Name Description
0x0218 7:0 R/W P1_SET Set by CBPro
0x0219 15:8 R/W P1_SET
0x021A 23:16 R/W P1_SET
0x021B 31:24 R/W P1_SET
Table 14.55. 0x021C-0x0221 P2 Dividers
Reg Address Bit Field Type Setting Name Description
0x021C 7:0 R/W P2 48-bit Integer Number
0x021D 15:8 R/W P2
0x021E 23:16 R/W P2
0x021F 31:24 R/W P2
0x0220 39:32 R/W P2
0x0221 47:40 R/W P2
Table 14.56. 0x0222-0x0225 P2 Divider Enable/Set
Reg Address Bit Field Type Setting Name Description
0x0222 7:0 R/W P2_SET Set by CBPro
0x0223 15:8 R/W P2_SET
0x0224 23:16 R/W P2_SET
0x0225 31:24 R/W P2_SET
