5. Operating guidelines
In the case of danger, switch the appliance off at the switch and pull out the
mains plug.
After running, the compressor will have hot surfaces inside the cabinet. If
touched, there is a risk of being burnt.
Automatic operation. When the pressure in pressure tank falls down to a
‘switch on’ pressure, the compressor is automatically switched on. The
compressor is automatically switched off when the pressure increases to the
‘switching off’ pressure in the pressure tank.
5.1 Switching on the compressor
The compressor is switched on by mains switch by putting it to position ‘I’. Switching
on of the compressor is signaled by the pilot-light.
When the pressure of the air at the ‘Inlet’ port is reduced or if there is a reduction of
pressure in the air chamber, the compressor is switched on and the air chamber is
filled with compressed air. After the ‘switching-off’ pressure is reached, the
compressor is automatically switched off. Pressure of the output air from the
compressor indicates the manometer (1).
During the operation of the compressor, the pointer of the humidity indicator (2),
should be in the green zone. If the consumption of air from an appliance is larger
that the maximal outflow (see technical data for details), the pointer of indicator will
move from the green zone and the air from compressor will not reach the required
parameters of pressure dew point.
The hour meter (3) indicates total running time of the air pump.
1
2
3
