SLE 350 - 12 Specification

Page 32 of 42
12. Specification
*The rated voltage and frequency can be changed by special order
SLE350 SLE500
Rated voltage / Frequency 230/50(60)V/Hz* 230/50(60)V/Hz*
Nominal current 2,8A 3,4A
Maximal output flow at maximum
pressure 3,5 bar
40Lit.min
-1
60Lit.min
-1
Filtration of air to 5µm 5µm
Pressure dew point at max. flow
40 l/min –1 and at an air pressure
of 3 bar. °C
5°C under the ambient
temperature
5°C under the ambient
temperature
Sound level 49dB(A) 49dB(A)
Mode of the operation of
compressor
Continuous S1 Continuous S1
Release of condensed water Automatic Automatic
Output pressure 3,5 bar 3,5 bar
Air chamber capacity 5Lit. 5Lit.
W o r k i n g p r e s s u r e o f t h e p u m p 5,0 – 7,0bar 5,0 – 7,0bar
Allowable operation pressure of
safety valve
8,0 bar 8,0 bar
Adjustment of the air pressure at
the output
Pressure regulator Pressure regulator
Dimensions of compressor
w x d x h
400x430x730mm 400x500x730mm
Dimensions of compressor in
packaging w x d x h
500x530x820mm 500x600x820mm
Weight of compressor 44kg 55kg
Weight of compressor in
packaging
60kg 75kg
Implementation according EN 60
601-1
EN 12 021
appliance of type B class I. appliance of type B class I.
