(Model K) Page 225
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
1 1 L4007 Infant Ventilator, Model K A RF
5 N6622 .Exhalation Block Assy 1
10 N21866/01 .Silencer, Long 1
15 T1267/M1 .Moulding, Case rear 1
Attaching Parts
20 H4116 ..Screw (M4 x 16mm) 5
25 H4095 ..Washer, nylon (M4) 5
30
T1297/01/UK/09
.Label, air vent
Part of the T1297/01/UK label set
1
35
T1297/01/UK
/06 .Label, Mains switch
Part of the T1297/01/UK label set
1
40
T129701/UK/
07 .Label, RS232
Part of the T1297/01/UK label set
1
45 P0407/01 .Cap, RS232 port 1
50 T129701/UK/05 .Label, O
2
cell cover plate
Part of the T1297/01/UK label set
1
55 T129701/UK/08 .Label, Do not block
Part of the T1297/01/UK label set
1
60 M0255/07 .Mains Cable, 13A moulded sq pin plug
(IEC/BS 1363/A)
1
-60A M0255/06 .Mains Cable, Schuko,
IEC socket
RF
-60B P0454/03 .Mains Cable, Nema,
5-15P Plug-IEC Socket
RF
Attaching Parts
65 M0303/01 ..Clip, P 1
70 H4108 ..Screw (M4 x 8mm) 1
85 M0457/2AC/001 Fuse, 2 amp RF
