SLE SLE4000 - Page 226

Page 226 (Model K)
- Item Not illustrated
1 90 T129701/UK/11 .Label, Fuse rating
Part of the T1297/01/UK label set
1
95 T129701/UK/10 .Label, Air O
2
inlet
Part of the T1297/01/UK label set
1
100 T129701/UK/04 .Label, Input pressures
Part of the T1297/01/UK label set
1
105 M0219 .Label, serial number 1

110 L0274/M3 .Base plate and side door assembly
(See figure 2 for detailed breakdown)
1
Attaching Parts
115 H3208 ..Screw (M3 x 8mm) 6

120 H4110 .Screw, trolley fixing (M4 x10mm) 2
125 H4094 .Washer, shakeproof (M4) 2

130 T1193/01 .Inner Cover 1
Attaching Parts
135 H3208 ..Screw (M3 x 8mm) 4
140 H4208 ..Screw (M4 x 8mm) 2

145 L4007-1002 .Front facia assembly
(See figure 3 for detailed breakdown)
1
Attaching Parts
150 H3108 ..Screw (M3 x 8mm) 6
155 H3094 .Washer, shakeproof (M3) 6
160 H3208 ..Screw (M3 x 8mm) 3

165 L0270 .Electronic module assembly
(See figure 4 for detailed breakdown)
1
170 L0288/KV .Pneumatic module assembly
Addition of Proximal airway modification
(See figure 5 for detailed breakdown)
1
Attaching Parts
175 H4108 ..Screw (M4 x 8mm) 7
180 H4094 .Washer, shakeproof (M4) 7

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
