Chapter 1 Welcome
docs.smarttech.com/kb/171897 7
Component Description In this guide
Pens The display comes with two pens, which users can
use to write or draw on the screen.
Replace a pen if its nib becomes worn to prevent
damage to the screen or impairment of pen and
finger detection.
Power status light |
Sensors
The power status light indicates the display’s
status:
l
When the power status light is red, the display
is in Standby mode.
l
When the power status light is green, the
display is in normal operating mode.
The display includes an infrared sensor that works
with the infrared remote control and an ambient
light sensor that can detect the brightness of the
room and adjust the screen’s brightness
accordingly.
You can enable or disable the ambient light
sensor feature.
Infrared remote control When you first install and configure the display,
you can use the infrared remote control to turn the
display on or off, switch inputs, and view and
change settings.
After installation and configuration, you can give
the remote to users for use with the display.
Home button Users can press the Home button to return to the
iQ home screen at any time.
Front control panel The front control panel contains buttons for
turning the display on and off, controlling the
volume, freezing and unfreezing the screen, and
showing and hiding a screen shade.
Front connector panel The front connector panel includes connectors for
up to two computers or other devices as well as
USB peripherals. It’s typically used to connect
users’ laptops and peripherals and other devices
users bring with them.
SeePage27
Side and bottom
connector panels
The side and bottom connector panels include
connectors for multiple computers, peripherals,
and other devices. They are typically used for
room computers, peripherals, and other devices
that are connected to the display all the time.
SeePage26
