22 smartmeter T20
8 Menu Packet Control
The smartmeter T20 also allows you to read the signal strength (S) and
signal quality (Q) of eight channels. Per default (after menu calling) this are
eight successive channels according to the channel spacing.
1. Press the
MENU key.
2. Using the ◄/► and ▲/▼ keys, select the
PACKET CONTROL
menu item and confirm your selection by pressing
OK.
8.1 Changing a Certain Transponder
1. Press the keys ◄/► (or F1/F2) to select one of the eight displayed
transponders.
2. Press OK to open a selection window.
3. Press the keys ▲/▼ to select the transponder to be displayed. Confirm
with
OK to go back to the submenu
TP IDE
.
8.2 Changing the Group of eight
Press F4 to display signal strength and signal quality of the next eight
transponders.
Press F3 to display signal strength and signal quality of the previous
eight transponders.
