Product Description
smartmeter T20 9
2.2 Meter
2.2.1 Front View
No.
Description
1
Aerial port
For connecting a DVB-T aerial (F-connector) to the me-
ter.
If the aerial uses a coaxial connector, use the supplied
adapter F-connector to coaxial connector to connect
the aerial.
2
LCD display
Displays the TV picture, the menu and the measured
values.
3 Function keys Functions vary across menus/submenus.
Functions are indicated at the bottom of the display.
