X
Turn bulb holder : anti-clockwise and
remove.
X
Remove the bulb out of bulb holder :.
X
Insert the new bulb into bulb holder :.
X
Insert bulb holder :
and
turn it clockwise
until it engages.
X
To fit the cover in the front wheel arch:
insert cover ; again and lock in place.
Dipped-beam/main-beam headlamps
X
Switch off the lights.
X
Open the service cover (Y page 173).
X
Remove cover :.
X
Pull out the connector.
X
Simultaneously press retainer ; forward
and to the right and then remove the lamp.
X
Insert the new bulb and engage it in place.
X
Insert the connector.
X
Position cover : and press into place.
Front foglamps
Due to their location, have the bulbs in the
front foglamps changed at a qualified spe-
cialist workshop.
X
Switch off the lights.
X
Remove the two screws : at the bottom of
the front wheel arch using a suitable tool.
X
Bend back the cover using your hand.
X
Turn the bulb holder anti-clockwise and
remove it.
X
Remove the bulb out of bulb holder.
X
Insert new bulb into the bulb holder.
X
Insert the bulb holder and turn it clockwise
until it engages.
X
Bend the cover back into position.
X
Tighten the two screws : again.
Side turn signal lamps
X
Insert a flat tool into recess : and lever
side turn signal lamp ;
forwards and out.
X
Remove
the bulb holder from side turn sig-
nal lamp ; by turning it a quarter turn
anti-clockwise.
X
Pull the bulb out of bulb holder.
X
Insert the new bulb into the bulb holder.
78
Replacing bulbs
>> Lights and windscreen wipers.
